Hanging sliding doors are also called sliding doors, moving doors, hanging sliding doors, etc., and are divided into hollow hanging doors, semi-automatic hanging doors, glass hanging doors, gravity hanging doors, etc. according to different materials and heights. At present, the hanging door profiles on the market are divided into titanium magnesium aluminum alloy and recycled aluminum. Then, the next editor will introduce you to the aluminum alloy hanging door , I hope to help you!
What is aluminum alloy sliding door
The aluminum alloy hanging sliding door is a door that does not have a track underneath, and mainly slides left and right in combination with the upper hanging rail and the hanging wheel. This door has no noise and no threshold when opening. It is beautiful and elegant.
Scope of application: living room and dining room, dining room and kitchen, toilet partition, etc.
Color: red walnut, black walnut, sapele, pure white, etc.
Hanging sliding door material: it is made of advanced aluminum alloy to make hanging rails, door frames and door leaf frames. (Aluminum alloy: it is an alloy formed by adding other metal elements to the aluminum ingot. Its outstanding features are small density, high strength, good corrosion resistance, good plasticity and high strength)
Installation of aluminum alloy hanging sliding door
1. If the package is opened between the door frame and the wall, carefully check whether the product and parts are intact.
2. Take out the door frame and place the front of the material upwards as much as possible to avoid scratches. It is best to lay cardboard or carpet on the ground.
3. Put the upper slide wheel into the upper chute in the correct order, assemble the frame and horizontal frame correctly and tighten with half-section self-tapping screws (the seam must be flat). Special note: pay attention to the arrangement position of the upper sliding wheel to avoid rework.
4. Put the assembled door frame into the door hole, first hang the left and right door frames horizontally and vertically, drill holes for positioning, and fix them with expansion screws. (The screws should not be too tight for fine adjustment when installing the door leaf.) The gap is too large. Then use a thin plate or other objects inside.
5. If there is a gas window, it should be horizontal and vertical. The square is above the guide rail, and the hole is fixed with expansion screws (if the gap in the wall is too large, it will be tightly fixed with thin wood chips). After the gas window is installed, the chute on the door Screw holes are fixed to the lower trough frame of the transom, and the door leaf without the transom is directly drilled with a drill at a suitable position on the upper chute, and fastened with a jacking screw (do not tighten the jacking screw too tightly for the next overall fine adjustment).
6. Finely adjust the whole door frame left and right, up and down to the same plane and keep it vertical, and then tighten all screws.
7. Whether the pulleys are at the same height and in line with the height of the site. If they are equal, the door leaf can be hung. If they do not match, adjust to a suitable position and then hang the door leaf (note: the correct direction of the front and back of the door leaf).
8. After hanging the door leaf, adjust the level of the upper pulley again. The traversing effect and the lock are accurate and ready to install the positioning wheel.
9. In the natural vertical state of the door, determine the installation position of the door leaf positioning wheel, draw a line, remove the door leaf, and press the correct screw of the positioning wheel to fix the positioning wheel.
10. Hang the door leaf to check whether the gap between the two doors is uniform from top to bottom. If not, adjust the door to the appropriate position and test the level of the door leaf. The wading effect and the smooth and safe opening of the lock, etc., until everything reaches the best effect, Remove the door leaf, tighten the positioning wheel screws, hang the door leaf again, and tighten the upper sliding wheel positioning adjustment screws.
Editor's conclusion: The above about what is the aluminum alloy hanging sliding door and the installation of the aluminum alloy hanging sliding door is roughly introduced here! I hope to bring you help in decoration. For more knowledge on home improvement, please pay attention to the information on this website!
